OVERVIEW

lron core:

The three-dimensional triangle roll is intimately composedof three identical single frames. The three core posts arearranged in an equilateral triangle. The magnetic pathlength of the three core posts is completely the same, andthe shortest. The loss of the three core posts is the same, sothe three-phase magnetic circuit is balanced.The productiorefficiency is improved, The three-dimensional triangularwound core is the same as the planar wound core in that it isrolled on the production line to eliminate the qualityfluctuations caused by manual lamination and stacking ofthe stacked iron core.At the same time, the body structure ofthe three-dimensional triangular wound iron coretransformer determines that its short circuit resistance isbetter than that of the planar transformer.

Oil tank:

The appearance is beautiful, the transformer oil tank adopts anear-micro triangle structure, so the volume is smaller thanthe conventional rectangular oil tank, the structure is compact,and the appearance is beautiful.
